SLSA Sport 2SE Specifications: These characteristics are for the SLSA as defined by the rule. Actual characteristics of the Sport 2S may differ. However where they differ they still meet the rule.  POWERPLANT PowerPlant Rotax 582 No. Cylinders 2 Displacement 580.7 cc Horsepower 65 hp Recommended TBO 300 hrs Propeller 72" in Length 18ft 3in Height 8ft 1/2 in Wingspan 30 ft 11 in Wing area 174.1 sq ft Wing loading 5.74 lb/sq ft Power loading 15.53 lb/hp Seats 2 Minimum weight crew 1 Empty Weight 444 lb Useful load 556 lb Payload w/full fuel. 520 lb Max takeoff weight 1000 lb Fuel capacity 12 U.S. gal  AIRSPEEDS Vx (Best angle of climb) 37 mph Vy (Best rate of climb) 43 mph Va (Design maneuvering) 70 mph Vne (Never exceed). 80 mph Vs1 (Stall, power off) 38 mph Lading approach speed 49 mph    PERFORMANCE Take off distance, ground roll 340 ft Takeoff distance, 50 ft obstacle 650 ft Rate of climb 430 ft/min Max level speed, sea level 61 mph Landing distance, 50 ft obstacle 580 ft Landing distance, ground roll 280 ft Glide Ratio 5.5:1 Minimum sink rate 660 ft/min  CRUISE PERFORMANCE CHART At 55% power (5300 rpm/mph) 46 mph At 65% power (5600 rpm/mph) 50 mph At 75% power (5900 rpm/mph) 58 mph At 100% power (6500 rpm/mph) 61 mph  FUEL FLOW  At 55% power (5300 rpm/gph) 3.5 gph (13.2 lph) 96 mi (154.5 km) At 65% power (5600 rpm/gph) 4.8 gph (18.2 lph) 75 mi (120.7 km) At 75% power (5900 rpm/gph) 5.6 gph (21.2 lph) 70 mi (112.6 km) At 100% power (6500 rpm/gph) 6.4 gph (28.4 lph) 72.5 mi (116.6 km)  KIT COST Contact local dealer or Quicksilver for Price

Features Reinforced landing gear Reinforced push pull elevator tube Tapered 3 Blade composite propeller for longer engine life Hydraulic wheel brakes Engine Instrument System Flight Instrumentation deck All specifications are based on manufacturers calculations. SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE This information is for reference only, please consult Quicksilver or one of it’s dealers for exact and up to date specifications.
